Visual Tools AX-TV: monitoring up to sixteen Onvif cameras on an HDMI TV or monitor

Compatible with Onvif cameras, the new version of the visual tools ax-tv video decoder makes it easy to view up to sixteen video signals from devices connected on the local network or over the internet on a tv or HDMI monitor without a pc-free view.

The AX-TV wireless device Visual Tools does not require a PC to view on a TV or HDMI monitor up to sixteen video signals from video surveillance cameras (Compatible with Onvif, including encoders and 360º device views) connected on the local network or via the Internet, both full screen and 2 quadrants×2, 3×3 and 4×4.

Small in size, this video decoder is especially suitable for offices, Clinical, Shops, hotels and businesses, among others, with up to sixteen cameras installed on the network.

AX-TV automatically detects devices and supports image formats 4:3 And 16:9, MJPEG or H.264 compression and different resolutions.

As long as the IP camera supports it, the system will present the captured images with an HDTV resolution of 1,280×720 Pixels; otherwise AX-TV will scale the image to occupy the full screen.

In quadrants of multiple viewfinders, the decoder only asks the cameras for the resolution at which they are displayed on the screen to optimize the bandwidth consumed that, if they are reduced, you can also limit the maximum resolution provided by these devices by editing their respective profiles from the settings menu.

AX-TV also allows you to set up rounds by choosing cameras and sequential viewing time, as well as motion control of PTZ cameras, EPTZ, 360º and megapixel, with an average transmission of 15 Ips. The system includes infrared control.
