Infaimon delivers Raven-640 high-resolution infrared camera, specific to security applications

As one of its novelties for the security sector, The distributor of machine vision and image analysis systems and components, Infaimon, has added the new Gobi Raven-640 infrared camera to its catalogue, 17μm, with a very high resolution of 640 X 480 pixels and a high-temperature operating range, Offering a crisp and clear thermal image, even in difficult weather conditions and in complete darkness without the use of additional lighting.

The Image Analysis and Machine Vision Solution Provider Infaimon offers the new Raven-640 analog camera, An infrared camera specifically designed to cater to the demanding security market. This camera produces accurate, high-quality images, even in outdoor applications in the open and in total darkness, without the need for additional lighting.

This camera incorporates a sensor with a higher resolution than most infrared cameras available today (640 X 480 Pixels) and is capable of detecting the slightest changes in temperature and objects of the smallest dimensions. To increase flexibility of use, The camera is compatible with different types of optics for visualization in the near-infrared spectra, Medium & Long. The camera can be configured in PAL/NTSC video modes for CCTV security applications and controlled by RS232.

The Raven-640 can be easily installed and used without prior training. It is ideal for border security applications, Ports, Airports, conventional or nuclear power plants and oil industry warehouses.

Features:

Sensor: Unrefrigerated microbolometer
Resolution: 640 X 480 Pixels
Pixel Size: 17 μm
Spectral sensitivity: 8 To 14 μm
Operating Temperature Range: -40ºC to +70ºC
Capture Speed: 30 Hz
RS232-based communication control (XSP)
PAL or NTSC output
Dimensions: 49 X 49 x 67mm
Weight: 200g
